Treat Faster Tools as a Profile, Not an Insult
I recently had this gracious github issue raised against scc related to another code counter mezura which has some impressive performance claims.
Naturally, I decided to check it out.
boyter@spongehead:/mnt/data/projects$ hyperfine 'scc ./linux' 'mezura ./linux'
Benchmark 1: scc ./linux
Time (mean ± σ): 512.2 ms ± 4.6 ms [User: 10362.5 ms, System: 985.7 ms]
Range (min … max): 506.6 ms … 519.5 ms 10 runs
Benchmark 2: mezura ./linux
Time (mean ± σ): 200.3 ms ± 9.6 ms [User: 2898.5 ms, System: 643.5 ms]
Range (min … max): 186.8 ms … 213.0 ms 14 runs
Summary
mezura ./linux ran
2.56 ± 0.13 times faster than scc ./linux
Damn, I just got Buster Scrugged.
At the time I was enjoying a splash of whisky to celebrate the wind down of a stressful project and keep my singing voice in fettle. I was astonished at the result. However, before trading my spurs for wings, I decided to sleep on it, and have a look around at what I could do.
As I said on the stto comparison some time ago,
This is not because I am hurt if my tool is slower. In fact that would make me happy, as I can learn from my mistakes.
So looking at the times, we have this on my Desktop, a 9950x3D and Go 1.27, rerun the next morning.
| wall | |
|---|---|
| scc 4.0.0 | 508.6 ms |
scc 4.0.0 -c |
445.7 ms |
| mezura 3.0.0 | 203.9 ms |
Two things of note. I used -c which turns off complexity calculations to make it a closer comparison since mezura does not do this (as far as I can tell) and secondly, they are not doing an equal amount of work. scc is counting ~86,000 files compared to mezura counting ~67,000. However there is still no reason scc should be taking 2x the wall clock time for this task.
Now I could go and read the source of mezura to see if there is some trick I’m missing, or as I decided, to black box it, by looking at strace output instead. This is because it gives a good idea of where to go looking for wins, and I have never really used it that much.
So with strace -f -c we get the following trimmed output, for scc
$ strace -f -c scc ./linux
...
% time seconds usecs/call calls errors syscall
------ ----------- ----------- --------- --------- ------------------
64.35 53.910948 401 134199 17220 futex
8.81 7.376690 19 383594 fcntl
8.13 6.811101 137 49644 3 nanosleep
6.51 5.454290 19 286428 1 newfstatat
4.73 3.964218 22 179668 read
2.47 2.069497 20 101958 6052 openat
2.22 1.860438 19 95905 close
2.20 1.844428 19 95898 95897 epoll_ctl
0.29 0.244940 20 12165 getdents64
...
------ ----------- ----------- --------- --------- ------------------
100.00 83.774760 62 1344953 119189 total
and for mezura
$ strace -f -c mezura ./linux/
...
% time seconds usecs/call calls errors syscall
------ ----------- ----------- --------- --------- ------------------
23.26 37.838034 266 141799 read
16.81 27.351788 1447 18896 clock_nanosleep
14.14 23.009323 264 86831 17772 statx
13.01 21.164892 267 79009 2 openat
12.72 20.698234 261 79007 close
11.09 18.040855 263 68393 lseek
3.16 5.138156 1394 3685 1139 futex
2.15 3.495083 263 13242 sched_yield
1.96 3.194394 263 12110 getdents64
...
------ ----------- ----------- --------- --------- ------------------
100.00 162.676907 316 514499 18915 total
Ignore the seconds column, it’s overhead from strace, call counts are what matters here.
The thing that stands out there to me is the total number of calls. I have scc doing almost 2.6x as many kernel calls to count only an extra 28% more files. From the above though there are four main things I think need to be looked at.
epoll_ctl: 95,898 calls, 95,897 errors. Almost every single one failed.fcntl: 383,594. Approximately four per file processed.newfstatat: 286,428. About three stats per file.futex: ~134,000. A symptom of thread starvation.
As predicted a lot of file processing, although the futex is a bit of a surprise considering how much effort I have put into scc.
So with the above in place I now know where to start looking. Looks like there is room for improvement.
futex
The futex line is a good place to start. It does not indicate a bug, but instead that a thread is being parked or woken up. This suggests that the fan out/in pipeline it has is not as optimal as I would have thought.
The pipeline in question looks a bit like this,
┌─────────────┐ ┌────────────┐ ┌───────────┐
│ │ ┌──────────────────────┐ │ │ ┌──────────────────────┐ │ │
│ Walker │───▶│ potentialFilesQueue │───▶│ stat file │───▶│ fileListQueue │───▶│ process │
│ │ └──────────────────────┘ │ │ └──────────────────────┘ │ │
└─────────────┘ └────────────┘ └───────────┘
Walker has a configurable but by default 8 goroutines feeding a queue of potential files to process. Stat file does more than just stat, it would check the size, check symlinks, check regex exclusions, detect languages. Assuming a file passed all those checks it is enqueued to fileListQueue where counting actually happens.
The problem was there was only one stat file process. As a result potentialFilesQueue was always 100% full and fileListQueue was 100% empty. How I missed this over the last few days I will never know, but I suspect that process was putting back-pressure on everything else, and once that was resolved the bottleneck shifted.
Simple fix, change it to have multiple goroutines doing that work. The result was futex calls dropped to ~5500 per run and the resulting program dropped its wall clock runtime by about 160ms. It also exposed some concurrency bugs in newFileJob which have been resolved.
epoll_ctl / newfstatat / fcntl
One of the things that scc does is call os.Open(path) a lot… once for every file in fact.
However this has a bit of overhead, because on Linux os.Open hands the descriptor to Go’s runtime poller, and for a regular file the kernel refuses it. It comes down to how the kernel itself handles things.
Replicating this is not hard,
package main
import (
"os"
"syscall"
)
func main() {
path := os.Args[2]
buf := make([]byte, 65536)
syscall.Write(1, []byte("--- START ---\n"))
if os.Args[1] == "osopen" {
f, _ := os.Open(path)
f.Read(buf)
f.Close()
} else {
fd, _ := syscall.Open(path, syscall.O_RDONLY|syscall.O_CLOEXEC, 0)
syscall.Read(fd, buf)
syscall.Close(fd)
}
syscall.Write(1, []byte("--- END ---\n"))
}
We can then use strace to get what’s actually happening,
$ go build -o openone main.go
$
$ strace -f -e trace=openat,fcntl,epoll_ctl,read,close,write ./openone osopen ./main.go 2>&1 >/dev/null | awk '/START/{p=1;next} /END/{p=0} p'
[pid 3320210] openat(AT_FDCWD, "./main.go", O_RDONLY|O_CLOEXEC) = 4
[pid 3320210] fcntl(4, F_GETFL) = 0x8000 (flags O_RDONLY|O_LARGEFILE)
[pid 3320210] fcntl(4, F_SETFL, O_RDONLY|O_NONBLOCK|O_LARGEFILE) = 0
[pid 3320210] epoll_ctl(5, EPOLL_CTL_ADD, 6, {events=EPOLLIN, data=0x57a1e8}) = 0
[pid 3320210] epoll_ctl(5, EPOLL_CTL_ADD, 4, {events=EPOLLIN|EPOLLOUT|EPOLLRDHUP|EPOLLET, data=0x3f874a620c000001}) = -1 EPERM (Operation not permitted)
[pid 3320210] fcntl(4, F_GETFL) = 0x8800 (flags O_RDONLY|O_NONBLOCK|O_LARGEFILE)
[pid 3320210] fcntl(4, F_SETFL, O_RDONLY|O_LARGEFILE) = 0
[pid 3320210] read(4, "package main\n\n import (\n "..., 65536) = 556
[pid 3320210] close(4) = 0
$
$ strace -f -e trace=openat,fcntl,epoll_ctl,read,close,write ./openone rawopen ./main.go 2>&1 >/dev/null | awk '/START/{p=1;next} /END/{p=0} p'
[pid 3320746] openat(AT_FDCWD, "./main.go", O_RDONLY|O_CLOEXEC) = 4
[pid 3320746] read(4, "package main\n\n import (\n "..., 65536) = 556
[pid 3320746] close(4) = 0
Five calls before a byte is read. Opens the file, makes it non-blocking, offers to epoll, gets told no, and puts the flag back. The kernel is doing the right thing here, epoll answers “would I/O on this block?”, and for a socket or pipe makes sense, but for a file on disk… which should always be ready. The raw open by contrast does none of that.
Note Go is not doing anything wrong here either, os.File is an abstraction covering sockets, pipes and files, so this is expected.
However on BSDs and macOS there is a switch for runtime.GOOS in os/file_unix.go that spends an fstat to find out it is a regular file and skip the whole thing. Linux is not in that list, and the comment right next to it says why,
// An error here indicates a failure to register
// with the netpoll system. That can happen for
// a file descriptor that is not supported by
// epoll/kqueue; for example, disk files on
// Linux systems.
That is the right trade when you are opening five files, but the wrong one when you are opening ninety thousand. Also knowing I am about to open 90,000 files is not something the library should be worrying about.
Switching to syscall.Open() resolves this overhead, gives you the file as before, but with fewer calls.
Measured on its own, using a single threaded process with warm cache, opening and reading 99,073 files of the kernel tree,
Benchmark 1: osopen
Time (mean ± σ): 346.1 ms ± 2.0 ms [User: 72.7 ms, System: 280.5 ms]
Benchmark 2: rawopen
Time (mean ± σ): 276.4 ms ± 4.2 ms [User: 26.0 ms, System: 255.6 ms]
Summary
rawopen ran 1.25 ± 0.02 times faster than osopen
Nice improvement there. Applying this fix to scc and we see a drop in fcntl from 383,594 down to 25,790 and epoll_ctl from 95,898 to 6,447.
One thing I should add before moving on though is that I am giving up what os.File does on Linux. I am now responsible for ensuring a syscall.Close is called or I will quickly hit the rlimit. Closing twice is a problem too because nothing is stopping it and if another goroutine grabs the same descriptor number I could close their file on them. EINTR handling is probably an issue on FUSE filesystems or network mounts too. None of this should affect scc because the descriptor only lives for a short time. But don’t do this on a long lived server.
Other
There were a heap of other tweaks that went into this, including some fixes in gocodewalker to help. Normally I would go into detail here, but I’ll be honest I forgot to keep my usual notes. Suffice to say while some bug fixes made it based on that bug report many were performance orientated. I suspect this is where the newfstatat stats were lowered, but I honestly don’t remember.
Results
So with the above fixes in place, where does scc land now? A quick comparison between the new build, the old one and mezura.
boyter@spongehead:/mnt/data/projects$ hyperfine './scc -c ./linux' 'scc -c ./linux' 'mezura ./linux'
Benchmark 1: ./scc -c ./linux
Time (mean ± σ): 192.4 ms ± 3.0 ms [User: 3815.7 ms, System: 882.9 ms]
Range (min … max): 187.5 ms … 197.5 ms 15 runs
Benchmark 2: scc -c ./linux
Time (mean ± σ): 456.6 ms ± 5.2 ms [User: 7276.0 ms, System: 983.7 ms]
Range (min … max): 447.2 ms … 468.5 ms 10 runs
Benchmark 3: mezura ./linux
Time (mean ± σ): 207.8 ms ± 10.5 ms [User: 2899.0 ms, System: 639.0 ms]
Range (min … max): 195.2 ms … 228.0 ms 13 runs
Summary
./scc -c ./linux ran
1.08 ± 0.06 times faster than mezura ./linux
2.37 ± 0.05 times faster than scc -c ./linux
Nice. Note we are still counting more files than mezura here (~86,000 to ~67,000), so the above is not an equal amount of work. However we are now running in half the time we were before.
Running on my M1 MacBook Air gives the following result of the new scc compared to the old one against my general projects directory.
$ hyperfine './scc ../' 'scc ../'
Benchmark 1: ./scc ../
Time (mean ± σ): 173.6 ms ± 10.2 ms [User: 374.4 ms, System: 292.0 ms]
Range (min … max): 155.6 ms … 189.4 ms 15 runs
Benchmark 2: scc ../
Time (mean ± σ): 386.1 ms ± 9.7 ms [User: 644.9 ms, System: 450.7 ms]
Range (min … max): 377.1 ms … 406.7 ms 10 runs
Summary
./scc ../ ran
2.22 ± 0.14 times faster than scc ../
No regressions on macOS.
But…. can we do better?
Engage Ludicrous Speed
So with mezura going into plaid, I need to engage ludicrous speed.
One idea I had bubbling in the back of my mind for a long time was to write optimised state machines for popular languages. The state machine that scc uses is designed to work for all languages. This makes adding a new one trivial. Set the rules of the language and it can now count it. However as we know, a generic solution to a problem is often not the most optimal.
The reason this could work well is you can optimise the state transitions to only what’s needed. Less code, fewer if conditions and less for the CPU to do. You can also start to implement other tricks. Take for example Java. If you find a line that starts with //. Assuming you just moved to a comment state, the only thing you need to do now is jump from that location to the first newline you see. The generic state machine has a harder time here because it was designed to read each byte.
But for this example, we can use Go’s AVX2 IndexByte once we find that // and use it to search multiple bytes in one pass to find that newline. This trick can potentially be applied in other areas too and should in theory provide a massive performance win.
I have never implemented this before now, because of the amount of work it involves. However with LLMs I can hand over the task, with the frames of reference, with a huge test suite, and with an implementation that already exists that can be used to confirm the outputs match 100%.
So I did exactly that. I handed over the exact details to Claude with exactly what I wanted and let it cook implementing this for C and Java. Results?
boyter@spongehead:/mnt/data/projects$ hyperfine './scc -c --exp-per-language-counters ./linux' 'mezura ./linux'
Benchmark 1: ./scc -c --exp-per-language-counters ./linux
Time (mean ± σ): 166.7 ms ± 2.9 ms [User: 2867.3 ms, System: 944.7 ms]
Range (min … max): 159.5 ms … 171.3 ms 17 runs
Benchmark 2: mezura ./linux
Time (mean ± σ): 203.4 ms ± 10.0 ms [User: 2871.4 ms, System: 655.7 ms]
Range (min … max): 189.7 ms … 218.7 ms 14 runs
Summary
./scc -c --exp-per-language-counters ./linux ran
1.22 ± 0.06 times faster than mezura ./linux
The exp-per-language-counters is just a flag I set to turn this functionality on. For now it is shipped off by default, until I am happy with its implementation. Probably in another version or two.
So… that’s processing 1,516,845,281 bytes in ~86,000 files… 1.9 µs per file (in wall clock time). I suspect we’re getting close to the limits of the hardware at this point? At least in terms of counting every byte in those files.
That’s about 9 GB/s of throughput, which I know is lower than the theoretical maximum a CPU can do, but still fairly impressive for non-contiguous file reads. Each file takes about 44 µs of CPU time to process, with the kernel itself spending about 10 µs of that just opening, reading, and closing the files. The machine has 16 physical cores and 32 threads, which with SMT scaling works out to roughly 23–24 effective cores. Dividing that 44 µs of work across those cores gives us that 1.9 µs wall-clock time per file. For this machine, that’s essentially 100% saturation. I guess io_uring might be the answer here, something for me to consider at a later date.
With the above done I have cut a new v4.1.0 release of scc with the above in it. Go get it. BTW, if you are running scc at scale, deploy this and see a nice change in your metrics please contact me as I’d love to see it.
In the end there was no trick in mezura I was missing. It was just me being stupid and missing some, in hindsight, obvious issues. Eventually your own mistakes catch up to you.
That issue ended with this line,
Thanks for scc, it pushes the rest of us to do better!
To which I say: no, thank you! You pushed me to do better!
